DIN rail power supply 15V 2A 30W ESPE | HDN-3015
DIN rail power supply 15V 2A 30W ESPE | HDN-3015
DIN rail power supply 15V 2A 30W ESPE | HDN-3015
DIN rail power supply 15V 2A 30W ESPE | HDN-3015

DIN rail power supply 15V 2A 30W ESPE | HDN-3015

57,99 PLN
incl. VAT / pcs
Regular price / pcs
of
You can also buy using:
28 days for free returns
Safe shopping
Product sold out
You will receive an email notification from us when the product is available again.
Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.
Contact details entered above are not used to send newsletters or other advertisements. When you sign up to be notified, you hereby agree to receive only a one-time notification of a product re-availability.

The ESPE-HDN3015  is a high-quality, high-performance switching power supply in a 2U wide plastic enclosure for mounting on a TS35 mm DIN rail. Its design is based on high-quality electronic components that allow for continuous, long-term operation. It is reliable, fully protected and stable. It provides high efficiency and excellent technical performance. The perforated housing provides good ventilation and the trimmer allows accurate voltage adjustment to compensate for voltage drop across the leads. Dual output terminals make it easy to connect loads.



SPECIFICATIONS:

input parameters:

  • input voltage range 100-240 VAC
  • Frequency range of mains supply voltage:  47-53 Hz
  • no-load power consumption: less than 0.15 W

output parameters:

  • regulation type: CV - constant output voltage
  • Rated output voltage: 15 V
  • output voltage trimmer control: 14,25-15,75V
  • Rated output power: 30W
  • Rated load current:  2 A
  • max. output voltage ripple: 150 mVp-p
  • energy conversion efficiency: over 85%

additional information:

  • operating temperature range: 0ºC to +40ºC
  • output protection:  overcurrent protection (OCP), short circuit protection (SCP), overvoltage protection (OVP)
  • input protection:  overvoltage (OVP), undervoltage (UVP)
  • MTBF: 30 h
  • dimensions: 90x58x35  mm
  • weight: 120 g
  • housing: IP20

characteristics:

  •  small dimensions
  •  high power output
  •  based on high-end electronic components
  •  All-protected, low surge current
  •  trimmer
  •  perforated housing
  •  LED indicator light

application:

  • industrial automation systems
  • alarm and monitoring systems
  • building automation installations
  • lighting systems
To download
Brand
Symbol
HDN-3015
Producer code
5904139605653
Series
input voltage AC
100-240VAC
output voltage DC (V)
15V
DC adjustment range
14,25-15,75V
output current (A)
2A
power (W)
30W
efficiency
85%
mains frequency range
47/53Hz
permissible temperature range
0º~+40ºC
IP rating
IP20
enclosure
tworzywo ABS
dimensons
90x58x35mm
weight
120g
